Place of Origin : Guangdong, China
Model Number : Grock
Brand Name : GCL
Packaging Details : plywood,flight case,paper board
Supply Ability : 5000 Square Meter/Square Meters per Month
MOQ : Min. order: 20
Price : Price to be discussed
Certification : EMC/CE/ROHS/CCC/FCC/BIS
Application : Outdoor, outdoor led display
Color : black
Panel Size : customized
Supplier Type : ODM, OEM
Media Available : EDA/CAD Models, Other
use : advertising publish
Pixel Pitch : 6mm, p6 p8 p10
Specification : Digital Poster, Video Wall
Brightness : 5000nits
Module size : 160*160mm
Cabinet material : Steel
Scan Method : 16/S
Cabinet Weight : 45kg/m2
Port : shenzhen
Grock | ||||
roduct | P5 | P6 | P8 | P10 |
Pitch(mm) | 5 | 6 | 8 | 10 |
Density(pixels/m2) | 40000 | 27777 | 15625 | 10000 |
LED Type | SMD1921 | SMD3535 | ||
Brightness(nits) | 6000 | 6500 | 6000 | 5500 |
Scan Method | 1/8 | 1/8 | 1/4 | 1/3 |
Cabinet Size(mm) | Customized | |||
Cabinet Material | Steel | |||
Cabinet Weight | 45kg/m2 | |||
Protection Level | IP65 | |||
Cabinet Maintenance | 100% Rear Service | |||
Max Power Consumption | 800w/㎡ | 720w/㎡ | 800w/㎡ | |
Average Power Consumption | 270w/㎡ | 240w/㎡ | 270w/㎡ | 280w/㎡ |
Refresh Rate | 2880-3840HZ | |||
Grey Scale | 16 bit | |||
Viewing Angle | H160,V140 | |||
Voltage | AC100~240V(50-63Hz) | |||
Working Temperature | -30 oC - + 65 oC | |||
Working Humidity | 10% -- 90%RH | |||
Color Temperature | 6500-9500K | |||
Certificationa | EMC/CE/ROHS/CCC/FCC/ISO |
![]() |
Double Sided LED Display Digital Signage for Advertising Publish and Video Wall Panel Images |
